Golden Power Chairs

Features for all Golden Compass Series chairs:

• Fold-flat seat for convenient transport
• Padded, flip-up arm support for effortless boarding and exiting
• Adjustable footrest for optimum leg and foot support
• Charges via socket for easy charging
• All chairs backed by 101 Mobility’s One-Year Limited Service Warranty in addition to the manufacturer’s warranty

Features for Compass HD chair only:

• Five height positions on seat for optimum comfort

Features for Compass Sport chair only:

• Three height positions on seat for optimum comfort

Compass HD

This chair boasts the largest weight capacity among its counterparts, ensuring strong support for various users.

Compass TRO

Equipped with Motion Concepts’ Power Tilt Seating System, this chair allows for electronic tilting up to a 55-degree angle, providing exceptional comfort and adjustability.

Compass Sport

Featuring the Dynamic Linx controller, this chair uses Dynamic Load Compensation to control motor speed and maintain a smooth ride, regardless of terrain or environment.

Options for all Golden Compass Series chairs

• Elevating leg rests – Provides two separate rests for each leg and foot for optimum comfort
• Oxygen tank holder kit – Attaches to back of seat for easy storage of oxygen tank
• Pack’n’go – Fabric pack that attaches to back of seat for toting
• Stump support – Provides a platform to rest stump for optimum comfort
• Swing-away leg rests – Provides two separate rests for each leg and foot and swings to side for easy storage
• Walker holder kit – Attaches to back of seat for easy storage of walker

Options for Compass HD and Compass TRO chairs only

• Cane/crutch holder kit – Attaches to back of seat for easy storage of crutches and/or cane
• Footplate extender – Increases size of footplate for optimum comfort

Options for Compass HD chair only

• Color – Available in two colors for added style:
  • Blue
  • Red
• Seat type and size – Available in three different types and sizes for optimum customization:
  • Captain’s Highback
    • Back height:
      • With headrest: 28.5” – 32.5” (724 mm – 825.5 mm)
      • Without headrest: 21” (533.4 mm)
    • Seat width:
      • 18” (457.2 mm)
      • 20” (508 mm)
      • 22” (559 mm)
      • 24” (609.6 mm)
    • Seat depth:
      • 18” (457.2 mm)
      • 20” (508 mm)
    • Seat color:
      • Charcoal/Gray
      • Coffee/Sand
    • Unit weight (without batteries): 152 lbs (69 kg)

• Pro-Flex
  • Seat width:
  • Seat depth:
    • 18” (457.2 mm)
    • 20” (508 mm)
  • Seat color: Black
  • Unit weight (without batteries): 149 lbs (66 kg)
  • Van/Pan
    • Back height:
    • Seat width:
      • 18” (457.2 mm)
      • 20” (508 mm)
      • 22” (559 mm)
      • 24” (609.6 mm)
    • Seat depth:
      • 16” (406.4 mm)
      • 18” (457.2 mm)
    • Seat color:
      • Charcoal/Gray
      • Coffee/Sand
    • Unit weight (without batteries): 149 lbs (67.6 kg)

Options for Compass TRO chair only

• Color – Available in four colors for added style:
  • Blue
  • Candy Apple Red
  • Hunter Green
  • Onyx
• Motion Concepts’ Power Tilt Seating System – Allows power chair to tilt electronically at a (maximum) 55-degree angle with only 7 inches (178 mm) of shift.
  • Technical specifications of Compass TRO with power tilt:
    • Turning radius: 21.95” (557.5 mm)
    • Overall chair length: 42.7” (1084.6 mm)
    • Overall chair width: 26.2” (665.5 mm)
    • Seat dimensions:
      • Minimum: 14” x 14” (355.6 mm x 355.6 mm)
      • Maximum: 22” x 20” (559 mm x 508 mm)
    • Unit weight (without batteries): 205 lbs (93 kg)
    • Positioning belt – Attaches to seat for secure user restraint during scooter operation
    • Seat type and size – Available in many different types and sizes for optimum customization:
      • Seat dimensions:
        • Minimum: 16” x 16” (406.4 mm x 406.4 mm)
        • Maximum: 24” x 20” (609.6 mm x 508 mm)
      • Seat color:
        • Coffee/Sand
        • Charcoal/Gray
        • Black Vinyl
      • Unit weight (without batteries) – Available in two unit weights (without batteries) for optimum customization:
        • 137 lbs (62 kg)
        • 139 lbs (63 kg)

Options for Compass Sport chair only

• Cane holder tube – Attaches to back of seat for easy can storage on chair
• Color – Available in two colors for added style:
  • Blue
  • Candy Apple Red
• Crutch holder tube – Attaches to back of seat for easy crutch storage on chair
• EZ Lock System – Allows for sturdy docking of power chair
• Power chair cover – Drapes over chair for chair protection when not in use
• Quad cane holder – Attaches to back of seat for easy storage of cane on chair
• Rear basket – Attaches to back of seat for toting and storage on chair
• Seat type and size – Available in two different types and sizes for optimum customization. Both seats feature adjustable depths:
  • Captain’s Seat
    • Back height:
      • With headrest: 26.5” – 29.5” (673.1 mm – 749.3 mm)
      • Without headrest: 19” (482.6 mm)
    • Seat dimensions: 18” x 18” (457.2 mm x 457.2 mm)
    • Seat color: Gray Vinyl
    • Unit weight (without batteries): 138 lbs (62.6 kg)
  • Captain’s Van/Pan
    • Back height:
      • With headrest: 30.5” – 34.5” (774.7 mm – 876.3 mm)
      • Without headrest: 23” (584.2 mm)
    • Seat dimensions: 18” x 18” (457.2 mm x 457.2 mm)
    • Seat color:
      • Charcoal/Gray
      • Coffee/Sand
    • Unit weight (without batteries): 132 lbs (59.9 kg)
    • Swing-away desk arm – Allows armrest to swing to side for easy boarding and exiting
